BorexStroke:?28 x 50mm
Max.Power Rating:?Up to 52HP
Working Pressure:?270Bar/3920psi
Max.Flow Rate:?92Lpm/24.3Gpm
Max.Input Rpm:?1000r/min
Head Material:?Stainless steel 420
Overall Dimension:?58x40x28cm
Shipping Weight:?66kgs
Pump Model: | DBG-2850 | |
Bore/Plunger Dia.: | 28mm | |
Stroke: | 50mm | |
Fluid End/Manifold Material: | Stainless steel 420 | |
Fluid End Material Options: | Die-cast aluminum alloy, anodized. |
|
Max Input POWER: | 38KW/52HP | |
Max Input RPM: | 1000RPM | |
Shaft Dia.: | 40mm | |
Inlet Port: | 1-1/2" BSP | |
Outlet Port: | 1" BSP | |
Oil Bath Capacity: | 3800ml (half level of oil gauge) | |
Oil Type: | 85W/90 or greater GEAR OIL | |
Water Inlet Pressure: | 0-50psi/3.5bar | |
Max Inlet Water Temp.: | 50℃/122℉ | |
Shipping Size.: | 58x40x28cm | |
Shipping Weight.: | 66kgs | |
Application: | High Pressure Water | |
